| General Description |
|
| 4
axes Numerical Controls for conventional or synchronized press-brakes. |
|
 |
The new DNC 60 is
designed for multi application purposes. Depending on which software it is equipped, the
DNC 60 can be used for synchronized or non-synchronized pressbrakes, with up-stroking or
down-stroking ram, shears, tube bending machines, straight side presses, automatic
machines, etc. The ease of programming allows the machine builder to configure all axes,
inputs/outputs and auxiliary functions according to his needs. |
|
|
|
The DNC 60 numerical
control can control up to 4 digital axes and many auxiliary functions. A backlight LCD
display (130x75mm) as well as a simplified keypad with large keys provide a high comfort
of use comparable to a high level numerical control. |
|
|
|
Depending on the
software, 4 to 11 languages are available directly in the DNC 60. The CYBELEC knowledge
offers with this new numerical control a quick programming appreciated by all machine
operators |
|
|
|
The DNC 60 is designed
to be easily integrated in a control panel or in the electrical cabinet. Well designed,
the housing protects the control electrically and mechanically and has its own mounting
hardware. The new DNC 60 holds all the electronic components on one single card using the
SMD technology. The FLASH memory permits, optionally, to update the software via the RS232
link. Simple commissioning as well as one single 24VDC-power supply reduces considerably
the installation and cabling. |
|
|
| Dimensions: |
|
|
Height: 290.0 mm |
|
Width: 239.0 mm |
|
Depth: 80.0 / 140.0
(with connectors) mm |
|
|
| CE Our numerical
controls comply with the EC Directives 89/336/EEC and 73/23/EEC |
