DNC 880S [click on image to enlarge]	[ back to previous page ]
		Dnc 880S Brochure
General Description
7 axes Numerical Controls for conventional or synchronized press-brakes and mechanical / hydraulic stops
The all new DNC 880S Windows XP Embedded numerical control, designed specifically for sheet metal working.
This compact unit is available in two versions (4 or 7 axis), and can be supplied in panel mount or enclosed design.
Superior quality 10" colour TFT display, simplified key panel and 2D graphic software make this control very comfortable to use.
The DNC 880S manages the hydraulic or mechanical crowning system and pressure proportional valve, calculates the bend allowance,  and proposes a simple page to program in seconds a part.
The DNC 880S is fully compatible with the earlier models DNC 80 and DNC 880, making it an ideal upgrade solution.
All DNC 880S versions are supplied with PC 1200 2D offline programming software.
DNC 880S PS For synchronized press brakes. 4 or 7 axes, 2 of them synchronized axes for the beam. DNC 884S PS or DNC 887S PS DNC 880S PC Like DNC 880S PS, but for press-brakes with mechanical (or hydraulic) stops and beam control by means of a linear encoder. The beam management with the linear encoder eliminates the fastidious adjustment of switches and makes possible different openings (top dead centre) for each sequence and automatic adjustment of PP (pinch point) for backgauge retraction. DNC 884S PC or DNC 887S PC DNC 880S P Like DNC 880S PC, but without beam control by means of a linear encoder. DNC 883S P or DNC 886S P
Dimensions:
Height: 465.0 mm Width: 350.0 mm Depth: 89.0 mm
Technical information
CE Our numerical controls comply with the EC Directives 89/336/EEC and 73/23/EEC
