ModEva - The remote console principle

In order to make ModEva succeed, Cybelec developed the remote numeric control console principle.
To be able to offer modularity, Cybelec opted to make the consoles independent of the CNC itself. This makes for a great freedom of choice of its user interface.

This remote console design is based on the Cybelec Panel Link  (CPL) technology that connects the console to the electric cabinet by just two standard (RJ45) cables so that Cybelec ModEva consoles can be placed more than 10 metres from the actual numerical control.

All ModEva consoles are equipped with the new Quick Cursor device.

Quick Cursor is a rotary button for rapidly and comfortably moving the cursor over the pages and for opening and selecting options in a menu. The change of pages and movement of axes in manual mode are also made possible with the same button. This greatly improves the ergonomics of numerical control.
At the graphic interface level, the ModEva range allies the recognised efficiency of CYBELEC with great simplicity of use supported by very intuitive programming.

One of its main features is the possibility of completely programming a part on a single page. For example, the average time to set up a triple-fold component, ready to be performed, is thus reduced to about thirty seconds.

When producing more complex parts, the graphic sequences generated by a CAD/CAM system can easily be viewed on the user console.

And then there is the fact that, in close co-operation with the main suppliers of CAD/CAM systems, CYBELEC, thanks to its openness, offers access to the simpliest as well as the most powerful of sheet metal modelling systems, as well as to software specialised in the interpretation of 2D or 3D files or those that offer a complete simulation. They can all transfer their results to the CYBELEC numeric controls in a very simple and user-friendly manner with a maximum of automation.

Electronic angle protractor

An electronic angle protractor connected to the ModEva allows to transmit the measured value directly to the numerical control which calculates immediately the correction.
This makes the adjustments quicker and reliable.

The transfer command is made by a button on the device or by a small pedal connected to the RS232 interface.

These are 2 measurement modes:

1. Simple:
   This mode requires only one measurement per angle (generally in the middle of the bending length).
2. Double:
   A measurement is carried out at each of the two extremities (or elsewhere) of the bend.
